Product Details:
|
| Appliaction: | Well Completion Tools | Casing Size: | 3 1/2 " |
|---|---|---|---|
| Type: | Soluble Bridge Plug | Dissolution Medium: | ≥0.05%KCL |
| Standard: | API | Working Condition: | Standard Servcie |
| Working Pressure: | 10000 Psi | Length: | 437 Mm |
| Highlight: | retrievable bridge plug,drillable bridge plug |
||
Downhole Bridge Plugs And Packers Soluble Bridge Plug 3 1/2" x 10000psi
Introudction of Soluble Bridge Plug
The Soluble Bridge Plug is a temporary fracture plug which is used for well completion oepration, the Soluble Bridge Plug is made of dissolvable metal and rubber material, and composed with mandrel, trust ring, wedge, element and guide etc.
Operation of the Soluble Bridge Plug
After Soluble Bridge Plug completely set, the shear screws connecting the tension sub to the mandrel shear, releasing the setting tool and adaptor kit from the packer.
When a dissolvable ball of Soluble Bridge Plug is landed on top of the plug after retrieving the setting tool and adaptor kit,frac plug provides zonal isolation for well stimulation. The large bore ID allows operator to produce through the plug while it remains in the wellbore and begins dissolution process immediately following fracturing. Both of the body and element can be dissolved, full bore ID is achieved after complete
dissolution.
Dissolving time of Soluble Bridge Plug
| Time(Day) | ||||||
| Temp.o | Water | 0.1% KCL | 1% KCL | 3% KCL | 8% KCL | 15% KCL |
| 25 | - | - | 15.1 | 11.4 | 10.5 | 11.6 |
| 40 | - | 13.6 | 8.4 | 7.6 | 7.3 | 7.8 |
| 55 | 60 | 13.2 | 7.9 | 7.2 | 7.1 | 7.2 |
| 70 | 56 | 10.6 | 6.5 | 5.7 | 5.4 | 5.6 |
| 85 | 30 | 7.3 | 4.7 | 3.8 | 3.2 | 3.8 |
About Techcore Oil Tools
Techcore Oil Tools has committed to the design of downhole tools for more than ten years.With the professional Research and Development (R&D) department and skilled engineers, Techcore improves the advanced technology in design and manufacture of the downhole oil tools .
In order to meet different requirement of downhole operation, in recent years, we joint with other factory who have accumulated abundant experiences in design and development the well completion tools, to manufacture and supply the oil well downhole tools, so that Techcore can offer one-stop purchasing service of downhole operation tools in well testing, well perforation, well completion.
Welcome to contact us for more information about the downhole tools and our best service!!
