Inconel Mechanical Tester Valve Inconel Full H2S service 5" x 10000 psi

Description
Appliction: Oil Well Drill Stem Testing Type: Mechanical Operated Tester Valve
Working Condition: Full H2S Service Material: Inconel
Size: 5" Standard: NACE MR0175
Working Pressure: 10000psi Connection: 3 7/8" CAS Box X Pin
High Light:

downhole valve

,

pressure safety valve

Inconel Mechanical Tester Valve Inconel Full H2S service 5" x 10000 psi



Introudction of Mechanical Tester Valve in Full H2S service



Mechanical tester valve is served as the master tester valve in the well testing working string. By lifting and lowering the drill pipe (or tubing) to control the ball valve, the mechanical tester valve is operated to open and close the well. The movement of the mechanical tester valve can be repeated many times as required. To use the Inconel raw material, the mechanical tester valve can be used for drill stem testing operation in Full H2S well condition.





Technical parameter of Mechanical Tester Valve



Tool Size 5″
OD 127.5mm
ID 57mm
Length 2991mm
Bottom and Top Differential of Ball 70MPa
Working pressure 140MPa
Shear Value NACE-0175 Sour Gas
Service Environment Full H2S
Working Temperature -29℃~+204℃
Connections Type 3 7/8″CAS.B×P
3 1/2″IF.B×P



Constructure of the mechanical tester valve



Mechanical tester valve consists of three major section: a inversion mechanism, a time-delay mechanism and a ball valve section.



* Inversion mechanism

The inversion mechanism consists of a J-slot mandrel and a transposition lug. There are many
index grooves on the J-slot mandrel. A pair lugs of transposition lug is inserted into the index groove.



* Time delay mechanism

The time delay mechanism consists of valve sleeve, metering cartridge, internal valve, outer valve, and oil case etc. This hydraulic time delay mechanism is a “one way” mechanism.



* Ball valve section

The ball valve section is comprised of top coupling, seat holder, ball valve cage, ball valve
assembly, operating pins and ball valve case etc. The ball valve is closed before the
circulating port is closed, this ensures that the circulating medium is separated from the
formation fluid.
