API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun

API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun
API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun

Large Image :  API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun

Product Details:
Place of Origin: CHINA
Brand Name: Techcore
Certification: ISO, BV
Model Number: PGF10021
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Polly wood, suitable for sea and air shipment
Delivery Time: 30-45 days
Supply Ability: 5 set/month

API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun

Description
Type: Mechanical Firing Head Application: TCP Operation
OD: 73 Mm Length: 15 Feet
Working Pressure: Max. 120 Mpa Standard: API
Material: Alloy Steel Part: Perforating Gun Parts
High Light:

well casing perforator

,

oil well fishing tools

API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun



Introduction of Mechanical Firing Head



The Sand-proof mechanical firing head is a kind of firing head which is applied in oil operation. It is initiated by dropping bar from the top of well bore to initiate detonating cord and booster, and then perforating charges.



Features of Mechanical Firing Head



* The sand proof mechanical firing head is with simple structure

* It is easy to operate the mechanical firing head.
* sand-proof and preclusive of blocking up, unavailable forwater in safe and reliable performance.
* Applied in vertical waterymud well and small-inclined well..







Specification of High Pressure Perforating Gun



Type WQFZ-A1 WQFZ-B1
OD

Φ60mm/2.4 in,Φ73mm/2.9 in,Φ89mm/3.5 in ,

Φ93mm/3.7 in and above

Max. Pressure 60MPa/8700 psi 120MPa/17400 psi
Max. Temperature

160℃/48h

140℃/100h

220℃/48h

200℃/100h

Min. Initiation Energy

Bar weight: 5±0.1kgdrop height: 0.7m

Non-initiation Energy

Bar weight: 2±0.1kgdrop height: 0.2m




API Oil Well Casing Perforation Sand proof Mechanical Firing Head Of Perforating Gun 0



About Techcore Oil Tools



With the professional Research and Development (R&D) department and skilled engineers whom were committed to the design of downhole tools for more than ten years, Techcore Oil Tools equipped with advance equipment is specialized in manufacture the oil downhole tools and its related parts in high quality.



* Techcore insist on superior quality, strong packing & timely delivery.

* Third party inspection is available from SGS, BV, DNV etc.

* Techcore do the best to supply thoughtful and prompt after-sales service to guarantee for the customers' benefits

* Techcore supply the cost effect products with 12 months guarantee



Welcome to contact us for more information!!
