10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve 4 3/4"

10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve  4 3/4"
10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve  4 3/4" 10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve  4 3/4"

Large Image :  10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve 4 3/4"

Product Details:
Place of Origin: CHINA
Brand Name: Techcore
Certification: ISO, BV,API
Model Number: SSSV505001
Payment & Shipping Terms:
Minimum Order Quantity: 1 sets
Price: Negotiable
Packaging Details: Polly wood, suitable for sea and air shipment
Delivery Time: 30-45 days
Supply Ability: 2000 sets/month

10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve 4 3/4"

Description
Material: Alloy Steel Working Pressure: 70 Mpa
Tool Size: 4 3/4" Connection: IF Box X Pin
Standard: API Working Condition: Standard Servcie
Application: Well Completion Operation Type: Downhole Safety Valve
High Light:

downhole completion tools

,

well completion equipment

10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve 4 3/4"



Introudction of Subsurface Control Valve



The Subsurface Control Valve is a kind of the downhole control valve which is used for drill stem testing operation and well completion operation. At the present, the subsurface control valve is developed for they models : SSC , SSC II and SSCIII. The Subsurface Control Valve is a combination valve and backoff joint, the valve allows the operators to close in a well that is being drilled without having to pull the workstring. This capability of the control valve is especially useful in offshore operations when storms are expected or when surface equipment. The SSC valve eliminates the hazard of leaving pipe standing in the derrick during a storm.





Features of Subsurface Control Valve



* The Subsurface Control Valve requires only right-hand rotation to release the workstring from the valve
* It is easy to operate the  Subsurface Control Valve in an emergency
* Subsurface Control Valve is desinged with full-flow bore.



Specification of the Subsurface Control Valve



OD 4.75”(120.7mm)
Min ID 1.25”(31.8mm)
Length 1737mm
Working pressure 70Mpa(10000psi)
Internal Pressure Strength 99Mpa
External Pressure Strength 92Mpa
Torque Strength 73kN.m
Tensile Strength 770KN
Working Temperature -29oC~204oC
Service H2S NACE MR0175
Connection Thread 3 1/2” IF BxP

   10000 PSI Oil Well Completion Tools Subsurface Control Valve SSC Valve  4 3/4" 0





About Techcore Oil Tools



With the professional Research and Development (R&D) department and skilled engineers whom were committed to the design of downhole tools for more than ten years, Techcore Oil Tools equipped with advance equipment is specialized in manufacture the oil downhole tools and its related parts in high quality.



* Techcore insist on superior quality, strong packing & timely delivery.

* Third party inspection is available from SGS, BV, DNV etc.

* Techcore do the best to supply thoughtful and prompt after-sales service to guarantee for the customers' benefits

* Techcore supply the cost effect products with 12 months guarantee

* Techcore insist on the traceability of each Drill stem testing tools and related DST parts



Welcome to contact us for more information!
